HUAWEI AX3 / AX3 Pro - AX3000 Router

HUAWEI AX3 Wi-Fi6 Router


HUAWEI AX3 / HUAWEI AX3 Proは、高速インターネットアクセスのある家庭向けに特別に設計されたWi-Fi6+ 対応のデュアルバンドギガビットワイヤレスルーターです。



Dimensions and Weight 225mm x 159.2mm x 39.7mm
2コア版: 約387g
4コア版: 約403g
日本向け: 225mm x 131.9mm x 30.9mm 430g
Wireless 802.11ax/ac/n/a 2 x 2 & 802.11ax/n/b/g 2 x 2
2 x 2 MU-MIMO
Wireless speed is up to 2976 Mbps (2.4 GHz: 574 Mbps; 5 GHz: 2402 Mbps)
Processors 2コア版: Gigahome Dual-core 1.2 GHz
4コア版: Kirin W650 Quad-core 1.4 GHz
Interface WAN: 1x 10/100/1000 Mbps Ethernet port LAN: 3x 10/100/1000 Mbps Ethernet ports
Button H button for one-key pairing and WPS compatible Independent Reset
LED Indicator 1 state indicator light
Power Supply 2コア版: 12 V DC, 1 A; Consumption < 12 W
4コア版: 12 V DC, 2 A; Consumption < 24 W
Software Functions APP: HUAWEI AI Life App
Huawei HiLink & 802.11v protocol
IPv4 / IPv6, PPPoE / DHCP / static IP address / Bridge WAN connection methods
Wi-Fi timer
Guest Wi-Fi
Device speed limiting
MAC address filter
Parental control
VPN pass through
DMZ / virtual server…
Security Anti-brute force algorithms
DMZ / DoS attack protection
4コア版のみ: TrustZone Security
